Features
Service and Guarantee
4. This machine is provided with lifetime technical support and one-year warranty service by Woodfung Machinery.
5. We provide global retail customers with a variety of platform transaction methods, and door-to-door shipping services.
Specification
| Model | WF360YC | Motor power | 19kw |
| Panel width | ≥60mm | Panel thickness | 10-60mm |
| Edge banding thickness | 0.4-3.0mm | Edge band width | 12-60mm |
| Feed speed | 0-13m/min | Working pressure | 0.7Mpa |
| size(LxWxH)cm | 550x110x165 | Weight | 2000KG |
| Edge band material | PVC, ABS, melamine, wood, acrylic, etc. | Custom range | Voltage, frequency, LOGO, paint color, shape, structure, function, etc. |
WF360YC functions:Pre-milling→ Gluing → End Cutting → Rough Trimming→ Fine Trimming →Scraping → Buffing
Automatic edge bander for different board and different edge bander
PAINTFREE,LAMINATE,PRATICAL,MDF,SOLID PANELS
SOFT VANEER,PVC,ACRYLIC,PMMA,ABS EDGE BANDERS
Automatic Edge bander application:
DELTA Touch Screen Operation Panel
Taiwan Delta PLC microcomputer control system adopts touch screen intelligent control, which is convenient, quick and easy to use
Pre-milling
Use double milling cutters to modify the marks and burrs to achieve a better edge banding effect
Gluing part
The glue pot is heated and glued, and the glue is coated with an imported technology structure to make the sheet and the edge banding evenly glued.
The edge band and the sheet are pressed tightly through the pressing wheel, and the adhesion is firm.
End Trimming
The front and rear aligning head is composed of the front aligning head and the rear aligning head. It moves through a linear CSK guide rail.
It adopts the structure of automatic tracking and high-frequency high-speed motor to make the cutting smooth
Rough Trimming
Rough trimming knife is used to leave a margin of 40-50 wire for fine trimming, and automatic die tracking and high-frequency
high-speed motor are used for rapid cutting.
Fine Trimming
The finishing knife is R2, leaving 5~6 wire allowance for scraping and trimming the arc with R2 trimming knife
Scrapping
It is used to eliminate the secondary wave marks caused by the cutting process of trimming non-linear motion, and make the upper
and lower parts of the board more smooth and tidy. At the same time, the scraping can also adjust the size of the arc to make the edge banding effect better.
Polishing
Use a plate polishing wheel to clean the processed plate, remove excess glue, and make the edge-sealing end surface smoother
For choice
Grooving
Horizontal grooving and back board grooving are used for direct grooving of side boards and door line grooving,
reducing the working procedures of panel saws and vertical milling machines. It is convenient and quick to form at one time.
Woodfung Brand Edge bander Automatic edge banding machine finished working
